Chauvin Arnoux CA5277 True RMS Digital Multimeter
Chauvin Arnoux CA5277 True RMS Digital Multimeter - Image 2
Chauvin Arnoux CA5277 True RMS Digital Multimeter - Image 3

Chauvin Arnoux CA5277 True RMS Digital Multimeter

Chauvin Arnoux

£332.00 / £398.40 incl VAT

  • True RMS digital multimeter with AC+DC measurement
  • Measures voltage up to 1000V and current up to 10A
  • Ionisation current testing for flame and smoke detectors
  • 5 measurements per second with 12-bit converter
  • Large dual backlit display with analogue bar graph
  • Peak capture, Min/Max, Relative and Differential modes
  • 3-year warranty

Available on back-order

Free Mainland GB Delivery on orders over £150 Fast Dispatch from our UK Warehouse Price Match Available on Many Products Need Advice? Call 01945 738112
Add a Multimeter Calibration Certificate?
SKU: CHA-CA5277 Category: Brand:

Description

Chauvin Arnoux CA5277 True RMS Digital Multimeter

The Chauvin Arnoux CA5277 True RMS Digital Multimeter is the highest-specification model in the CA5270 series, designed for professional testing, maintenance, troubleshooting, and inspection applications. Delivering exceptional precision and advanced diagnostic capabilities, the CA5277 combines True RMS AC+DC measurement technology with a high-speed 12-bit converter capable of performing up to 5 measurements per second for accurate readings on both linear and non-linear signals.

Engineered for demanding electrical environments, the CA5277 measures AC/DC voltage up to 1000V, AC/DC current up to 10A, resistance up to 60MΩ, frequency up to 50kHz, capacitance up to 60mF, and temperature from -59.6°C to 1200°C. It also includes continuity and diode testing, alongside a specialised ionisation current measurement range from 0.2µA to 20µA, ideal for testing flame detectors, smoke detectors, and similar systems.

The large dual 6,000-count backlit display features a bi-mode analogue bar graph with central zero for clear visualisation of fluctuating measurements. Advanced functions including Min/Max recording, Relative and Differential measurements, and 1ms Peak+/Peak- capture provide deeper insight into waveform distortion, transient events, and harmonic disturbances.

Designed with safety and durability in mind, the CA5277 is CAT IV 600V and CAT III 1000V rated, with IP54 ingress protection against dust and splashes. Its robust protective casing, integrated Multifix™ mounting system, and supplied accessories make it a reliable solution for field and workshop use alike.

Key Features

  • True RMS AC+DC measurements for accurate readings on non-linear signals
  • High-speed 12-bit converter with 5 measurements per second
  • Measures AC/DC voltage up to 1000V
  • Measures AC/DC current up to 10A (20A for 30 seconds)
  • Resistance measurement up to 60MΩ
  • Frequency measurement up to 50kHz
  • Capacitance measurement up to 60mF
  • Temperature measurement from -59.6°C to 1200°C
  • Ionisation current measurement range from 0.2µA to 20µA
  • Low impedance VLowZ AC voltage measurement with low-pass filter
  • Double 6,000-count backlit display with analogue bar graph
  • Peak+ and Peak- capture with 1ms response time
  • Min/Max, Relative, and Differential measurement functions
  • Audible continuity and diode testing
  • Automatic or manual range selection
  • IP54-rated splash-proof housing
  • CAT IV 600V / CAT III 1000V safety rating
  • Supplied with 3-year warranty

What’s Included

  • Chauvin Arnoux CA5277 True RMS Digital Multimeter
  • Thermocouple probe
  • Test leads
  • Test probes
  • 9V battery
  • Protective carrying case
  • Multifix™ mount
  • User instructions
SpecificationChauvin Arnoux CA5277
Display2 x 6,000 counts with backlighting
Bargraph61+2 elements, dual mode (full scale/central zero)
AcquisitionTRMS AC/DC/AC+DC
Measurement Rate5 measurements/second
Autorange / DeactivatableYes / Yes
Automatic AC/DC DetectionNo
V DC Ranges60 mV / 600 mV / 6 V / 60 V / 600 V / 1,000 V
V DC Typical Accuracy0.09% + 2 cts
V DC Resolution0.01 mV to 1 V
V AC Ranges60 mV / 600 mV / 6 V / 60 V / 600 V / 1,000 V
V AC Resolution0.01 mV to 1 V
Bandwidth40 Hz to 10 kHz
VLowZ ACYes
VLowZ AC Ranges600 mV / 6 V / 60 V / 600 V / 1000 V
VLowZ AC Resolution0.1 mV to 1 V
V AC+DC Ranges60 mV / 600 mV / 6 V / 60 V / 600 V / 1,000 V
V AC+DC Resolution0.01 mV to 1 V
A DC Ranges6000 µA / 60 mA / 600 mA / 6 A / 10 A (20 A / 30 s)
A DC Resolution1 µA to 0.01 A
Ionization Current0.2 µA to 20.0 µA
A AC Ranges6000 µA / 60 mA / 600 mA / 6 A / 10 A (20 A / 30 s)
A AC Resolution1 µA to 0.01 A
A AC+DC Ranges6000 µA / 60 mA / 600 mA / 6 A / 10 A (20 A / 30 s)
A AC+DC Resolution1 µA to 0.01 A
Resistance Ranges600 Ω / 6 kΩ / 60 kΩ / 600 kΩ / 6 MΩ / 60 MΩ
Resistance Resolution0.1 Ω to 0.1 MΩ
Audible Continuity / Diode TestYes / Yes
Frequency Ranges600 Hz / 6 kHz / 50 kHz
Frequency Resolution0.1 Hz to 10 Hz
Capacitance Ranges6 nF / 60 nF / 600 nF / 6 µF / 60 µF / 600 µF / 6 mF / 60 mF
Capacitance Resolution0.001 nF (1 pF) to 10 µF
Temperature Measurement Range-59.6 °C to +1,200 °C / -4 °F to +2,192 °F
Temperature Resolution0.1 ° to 1 °
Hold FunctionYes
Min / MAX (100 ms)Yes
Peak+ / Peak- (1 ms)Yes
Differential (∆X) / Relative (∆X/X%)Yes
Automatic Power-OffYes (deactivatable)
Safety RatingCAT IV 600 V / CAT III 1000 V
Ingress ProtectionIP54
Power Supply1 x 9 V
Dimensions / Weight90 x 190 x 45 mm / 400 g
  • Chauvin Arnoux CA5277 True RMS Digital Multimeter
  • Thermocouple probe
  • Test leads
  • Test probes
  • 9V battery
  • Protective carrying case
  • Multifix™ mount
  • User instructions

Click Here – For CA5277 Specifications
