Chauvin Arnoux MTX202 TRMS Digital Multimeter


£155.00 / £186.00 incl VAT
- TRMS AC/DC digital multimeter with automatic ranging for simplified measurements
- Measures voltage up to 1000 V and current up to 10 A
- Features MIN/MAX, HOLD, ΔREL, and NCV functions
- Large 6,000 count backlit display with integrated torch
- Supplied with magnetized shockproof sheath for hands-free use
- CAT III 600 V and IP54 rated for professional electrical maintenance
- 2 Year Warranty
Available on back-order
Description
Chauvin Arnoux MTX202 TRMS Digital Multimeter 1000V CAT III
The Chauvin Arnoux MTX202 TRMS Digital Multimeter is a compact and versatile handheld multimeter designed for electrical maintenance, troubleshooting, and field service applications. Offering TRMS AC/DC voltage and current measurements with automatic ranging, the MTX202 provides accurate and reliable readings for professional electricians, maintenance engineers, and HVAC technicians.
Designed for ease of use in demanding environments, the MTX202 features a large 6,000 count backlit display, built-in torch, and a rugged magnetized shockproof sheath for convenient hands-free operation. The ergonomic compact housing fits comfortably in one hand, while the two-position stand and Multifix mounting system allow flexible positioning on cabinet doors, belts, or workstations.
The MTX202 includes a wide range of measurement functions including voltage, current, resistance, capacitance, temperature, continuity, and diode testing. Additional features such as MIN/MAX recording, HOLD, ΔREL relative measurements, and NCV non-contact voltage detection improve efficiency during electrical testing and diagnostics. The integrated VLowZ low-impedance voltage measurement function also helps eliminate ghost voltages during troubleshooting.
Supplied with a K-type thermocouple for temperature measurements up to +1200°C, the Chauvin Arnoux MTX202 is ideal for electrical maintenance, PCB troubleshooting, HVAC servicing, and general-purpose industrial testing applications.
Key Features
- TRMS AC/DC voltage and current measurements
- Automatic ranging for simplified operation
- 6,000 count backlit display
- Built-in torch for low-light working conditions
- NCV non-contact voltage detection
- MIN/MAX, HOLD, and ΔREL functions
- VLowZ low-impedance voltage measurement
- Resistance, capacitance, continuity, and diode testing
- Temperature measurement with supplied K-type thermocouple
- Magnetized shockproof sheath for hands-free use
- Compact ergonomic design
- CAT III 600 V safety rating
What’s Included
- Chauvin Arnoux MTX202 TRMS Digital Multimeter
- K-type thermocouple
- Test leads
- Magnetized shockproof sheath
- User documentation
| Specification | Details |
|---|---|
| Dimensions | 170 x 80 x 50 mm |
| Weight | 320 g (with batteries) |
| Power Supply | 2 x 1.5 V AA batteries |
| Battery Life | Approx. 500 hours (VLowZ / VAC without backlight) |
| Reference Temperature | +23°C ±3°C |
| Operating Temperature | -20°C to +55°C |
| Storage Temperature | -40°C to +60°C |
| Relative Humidity | <90% RH (up to 45°C, non-condensing) |
| Protection Rating | IP54 |
| Safety Standards | IEC 61010-1 / EN 61010-2-030 / EN 61010-2-033 |
| Insulation | Class 2 double insulation |
| Pollution Degree | 2 |
| Usage Environment | Indoor use |
| Maximum Altitude | <2000 m |
| Measurement Category | CAT III 600 V |
| EMC Compliance | EN 61326-1 compliant |
| Measurement Type | TRMS |
| AC Signal Frequency Range | 45–65 Hz |
| Reference Humidity | 45% to 75% RH |
| AC/DC Measurement Characteristics | AC ≤0.1% of DC signal / DC <0.1% of AC signal |
- Chauvin Arnoux MTX202 TRMS Digital Multimeter
- K-type thermocouple
- Test leads
- Magnetized shockproof sheath
- User documentation
