Fluke 87V True RMS Industrial Digital Multimeter with Temperature Measurement

£456.00 / £380.00 excl VAT
⚡ 0.05% DC accuracy
⚡ 6000 counts, 3-3/4 digits
⚡ 4-1/2 digit mode for precise measurements (20,000 counts)
⚡ Measure up to 1000 VAC and DC
⚡ Fluke Lifetime Warranty
Description
Fluke 87V True RMS Industrial Digital Multimeter with Temperature Measurement
Product Details:
The Fluke 87V’s an industrial-grade DMM that’s also an improvement over the Fluke 83V, a more basic model of this multimeter. This device boasts all of the features found on the 83V as well as a selection of unique functions that are completely exclusive to this model.
Made for use in industrial environments, the Fluke 87V’s perfectly acceptable for use in troubleshooting, testing and general maintenance in power distribution, plant automation and use on all electro-mechanical industrial equipment.
Key Features:
- Unique function for accurate voltage and frequency measurements on adjustable speed motor drives and other electrically noisy equipment
- Built-in thermometer conveniently allows you to take temperature readings without having to carry a separate instrument
- Optional magnetic hanger for easy set-up and viewing while freeing your hands for other tasks
- Large digit display with bright, two-level backlight makes the 87V significantly easier to read than older models
- True RMS AC voltage and current for accurate measurements on nonlinear signals
- Selectable filter for accurate voltage and frequency measurements on motor drives
- 0.05% DC accuracy
- 6000 counts, 3-3/4 digits
- 4-1/2 digit mode for precise measurements (20,000 counts)
- Measure up to 1000 VAC and DC
- Measure up to 10 A, 20 A for up to 30 seconds
- Built-in thermometer lets you carry one less tool (TC probe included)
- Frequency to 200 kHz and % duty cycle
- Resistance, continuity, and diode test
- 10,000 µF capacitance range for components and motor caps
- Min/Max-Average recording with Min/Max Alert to capture variations automatically
- Peak capture to record transients as fast as 250 µs
- Relative mode to remove test lead interference from low ohms measurements
- Auto and manual ranging for maximum flexibility
- Touch Hold to capture stable readings avoiding noisy signals
- Large display digits and two-level bright white backlight for increased visibility
- Analog bar graph for fast changing or unstable signals
- Input Alert provides audible warning against wrong use of input jacks
- Improved selectable sleep mode for long battery life
- Access door for fast battery changes without breaking the calibration seal
- “Classic” design with a new removable holster with built-in test lead and probe storage
Voltage DC | |
Maximum Voltage | 1000V |
Accuracy | ±(0.05% 1) |
Maximum Resolution | 10μV |
Voltage AC | |
Maximum Voltage | 1000V |
Accuracy | ±(0.7% 2) true RMS |
AO Bandwidth | 20kHz with low pass filter; 3dB @ 1kHz |
Maximum Resolution | 0.1mV |
Current DC | |
Maximum Current | 10A (20A for 30 seconds max) |
Accuracy | ±(0.2% 2) |
Maximum Resolution | 0.01μA |
Current AC | |
Maximum Current | 10A (20A for 30 seconds max) |
Accuracy | ±(0.1% 2) true RMS |
Maximum Resolution | 0.1μA |
Resistance | |
Max Resistance | 50MΩ |
Accuracy | ±(0.2% 1) |
Maximum Resolution | 0.1Ω |
Capacitance | |
Maximum Capacitance | 9999μF |
Accuracy | ±(1% 2) |
Maximum Resolution | 0.01nF |
Frequency | |
Maximum Frequency | 200kHz |
Accuracy | ±(0.005% 1) |
Maximum Resolution | 0.01Hz |
Duty Cycle | |
Maximum Duty Cycle | 99.9% |
Accuracy | ±(0.2% per kHz 0.1%) |
Maximum Resolution | 0.1% |
Temperature | |
Measurement Ranges | -200 to 1090°C -328 to 1994°F (excluding probe) |
Conductance | |
Maximum | 60.00nS |
Accuracy | ±(1.0% 10) |
Maximum Resolution | 0.01nS |
Diode | |
Range | 3V |
Resolution | 1mV |
Accuracy | ±(2% 1) |
Duty Cycle | |
Accuracy | Within ±(0.2% per kHz 0.1%) |
Environmental Specifications | |
Operating Temperature | -20 to 55°C |
Storage Temperature | -40 to 60°C |
Humidity (Without Condensation) | 0 to 90% (0 to 35°C) 0 to 70% (35 to 55°C) |
Operating Altitude | 2000m |
Safety Specifications | |
Overvoltage Category | EN 61010-1 to 1000V CAT III, 600V CAT IV |
Agency Approvals | UL, CSA, T-V, VDE listed |
Mechanical/General Specifications | |
Size | 201 x 98 x 52mm (with holster) |
Weight | 355g (624g with holster) |
Display | Digital – 6000 counts, updates 4/sec (19999 counts in high resolution mode) Analogue – 32 segments, updates 40/sec Frequency – 19999 counts, updates 3/sec at >10Hz |
Warranty | Lifetime |
Battery Life | Alkaline – 400 hours typical (without backlight) |
Shock | 1m drop-tested per IEC 61010-1: 2001 |
Vibration | Per MIL-PRF-28800 for a class 2 instrument |
- Fluke 87V multimeter
- TL75 test leads
- AC175 Alligator Clips
- 9V battery
- 80BK temperature probe and holster
