Kewtech LOOPCHECK 107 Full Socket Tester With A Loop Check With Mains Polarity And RCD

Description

Kewtech LOOPCHECK 107 Full Socket Tester With A Loop Check With Mains Polarity And RCD

2 Years Kewtech Warranty

Product Details

• Checks-correct socket outlet wiring.
• Checks the quality of the earthing that is essential for safe installations.
• Checks-for the polarity of the mains supply.
• Checks RCDs with measured current.

The Kewtech Loopcheck 107 socket tester provides an easy, cost-effective solution to those looking to check correct outlet wiring and the quality of the earthing.

Using the Loopcheck is extremely simple, with little user interaction required.After placing inside a socket the Loopcheck will immediately start getting to work as it performs a wiring check, any detected faults will then immediately be signaled via red & orange LEDs as well as a warble tone. The position of the LEDs within the device corespond to the polarity of the pins, providing an obvious identifier to where a potential issue is located.

Once a wiring check has finalised and the socket polarity’s determined appropriate the tester initiates a test, at mains frequency, to check the quality of the earth loop. The condition of the earth loop return path’s then displayed via three differently coloured LEDs.

By touching the left hand touch pad, the Loopcheck 107 is also capable of checking the polarity of the mains supply. The right hand touch pad can generate a measured tripping current, which can check the operation of 30mA RCDs.
