Metrel MI2883 Energy Master Class S Power Quality Analyser
Price range: £1,255.32 through £1,958.22
⚡ Three-channel TRMS voltage and four-channel TRMS current measurement with peak values and crest factor
⚡ Comprehensive power metrics: active, reactive, harmonic, unbalance, and power factor (cosφ) calculations
⚡ Advanced analysis: harmonic and interharmonic analysis, THD measurement, and event recording (shutdowns, dips, swells)
⚡ Includes intuitive PC SW PowerView3 software for data transfer and professional report generation
⚡ Two set options: Standard (with test probes, SD card, and accessories) or Euro (adds three flexible 1-phase current clamps up to 3000A)
Description
Metrel MI2883 Energy Master Class S Power Quality Analyser
Product Details:
The Metrel MI2883 Energy Master Class S Power Quality Analyser is a handheld datalogger designed to measure a wide range of variables to assess the efficiency of an electrical power supply. It can also identify irregular consumption patterns, helping to reduce energy costs and prevent production losses due to faulty equipment. Depending on the memory card capacity, the analyser can remain in place for over a year, making it ideal for monitoring power correction systems, performing long-term analysis, supporting preventative maintenance, and verifying system capacity.
The Metrel MI2883 features True RMS (TRMS) measurement for voltage (3-channel) and current (4-channel), including peak values and crest factor. It also measures various power metrics such as active, non-active, fundamental, harmonic, and load imbalance, all in compliance with IEEE 1459. Power factor (cosφ) is also calculated.
Additional analysis capabilities include temperature measurement, harmonic and interharmonic analysis up to the 50th order, Total Harmonic Distortion (THD) measurement, as well as unbalance and flicker measurement. All power quality analysis functions conform to the EN 50160 standard, and the analyser can detect power supply events such as shutdowns, interruptions, swells, and dips.
The Metrel MI2883 allows up to 7 adjustable alarms to notify the user of specific issues, with events saved to its internal memory. The device comes with an 8GB micro-SD card that can store thousands of results and is capable of automatically recognizing and configuring up to four attached smart clamps.
Despite its comprehensive measurement and analysis capabilities, the Metrel MI2883 is user-friendly, featuring a large display and intuitive menu. It also includes Metrel’s PC SW PowerView3 Software for easy data transfer and the creation of professional test reports.
The Metrel MI2883 is available in two set options. The standard set includes test probes, crocodile clips, an 8GB micro-SD card, PC SW PowerView3 software, a USB cable, and a carry case. The Eurotest version adds three Metrel A1227 one-phase flexible current clamps with a range of up to 3000A.
Metrel part number: MI2883
Key Features:
- Three-channel voltage measurement (TRMS, peak, crest factor)
- Four-channel current measurement (TRMS, peak, crest factor)
- Power (active, reactive, apparent)
- Unbalance/flicker measurement
- Harmonic analysis
- THD measurement
- Energy measurement (active, reactive, generated, consumed)
- Records power supply events
- Up to 7 adjustable alarms
- Temperature measurement
- Power factor cosφ
- 8GB micro-SD card included
- Software package included
What’s In The Box?
Standard Set
- Metrel MI2883 Power Quality Analyser
- Test probe, (brown, black, grey, blue), 4 pcs
- Crocodile clip, (brown, black, grey, blue), 4 pcs
- Voltage measurement lead, (brown, black, grey, blue), 4 pcs
- Labels for color coding
- MicroSD memory card 8.0GB
- MicroSD card reader
- PC SW PowerView3
- USB cable
- Power supply adapter
- 1.2 V NiMH rechargeable battery, 6 pcs
- Soft carrying bag
- Instruction manual
- Calibration certificate
