Metrel MI3242 2A Micro Ohmmeter

Metrel

£886.00 / £1,063.20 incl VAT

⚡ Resistance measurement up to 1Ω and a micro-resolution of 0.1µΩ
⚡ Fully adjustable test current range from 20A to 200A
⚡ Waterproof outer casing and internal cooling system for safe operation

Available on back-order

SKU: MET-MI3242 Category: Brand:

Description

Metrel MI3242 2A Micro Ohmmeter

Product Description:

The Metrel MI3242 2A Micro Ohmmeter is a compact, lightweight, and highly accurate measuring instrument designed for low resistance testing in a wide range of applications. With the ability to measure resistance from as low as 1 μΩ up to 1999 Ω using a test current of up to 2A, this portable ohmmeter is particularly suited for fieldwork involving switches, relays, circuit breakers, connectors, power transformers, inductors, cable resistance, and more.

Its robust construction and CAT III / 600V overvoltage protection ensure user safety and instrument durability, even in demanding environments. The MI3242 supports bidirectional resistance measurements and is equipped with 50 Hz / 60 Hz ripple detection and rejection for precise and interference-free results.

Designed for user convenience, this meter features a large, backlit LCD for easy visibility in low-light settings and integrates intuitive pass/fail evaluation through pre-programmed limit settings, accompanied by green/red visual indicators. With an internal battery supporting over 800 measurements under typical conditions and a built-in memory capable of storing up to 1500 results with timestamps, users can rely on this instrument for extended sessions in the field.

All recorded data can be downloaded, reviewed, and printed using the included HVLink PRO software, ensuring efficient documentation and reporting of test results.

Key Features:

  • Measures low resistance from 1 μΩ to 1999 Ω with test currents up to 2A
  • High overvoltage protection (CAT III / 600V) for maximum safety
  • Internal safety protection circuit for user and device protection
  • Supports bidirectional resistance measurements
  • 50 Hz / 60 Hz ripple detection and rejection for improved accuracy
  • Performs over 800 measurements (500 mΩ load, 2A current, 15s duration) on a single battery charge
  • Internal memory can store up to 1500 test results with timestamps
  • Clear PASS/FAIL indication with green/red LED indicators based on pre-set limits
  • Large, backlit LCD screen for easy reading in low light
  • Data management and reporting through HVLink PRO PC software

What’s Included:

  • Metrel MI3242 2A Micro Ohmmeter
  • 2.5m 4-wire test cable
  • 4 x Crocodile clips (2 black, 2 red)
  • 2 x Test probes
  • Power supply adapter
  • 6 x 1.2V NiMH rechargeable batteries
  • RS232 serial cable
  • USB cable
  • Soft carrying bag
  • PC software HVLink PRO
  • Instruction manual
  • Calibration certificate
