Micronics UF D5500 Fixed Clamp-on Flow Meter

Micronics

£3,149.00 / £3,778.80 incl VAT

  • To suit pipes 12.7mm-4500mm
  • No Pipe cutting, No contact, Non-invasive sensing
  • Easy to use
  • Watertight enclosure
  • 26 million point data logger now as standard
  • Improved signal stability
  • Enhanced diagnostics

Available on back-order

SKU: MIC-UF-D5500 Category: Brand:

Description

Micronics UF D5500 Fixed Clamp-on Flow Meter

The Micronics UF D5500 is a fixed, non-invasive clamp-on ultrasonic Doppler flow meter designed for monitoring dirty, aerated, and solids-bearing liquids. Ideal for applications including wastewater, sewage, chemicals, acids, slurries, abrasives, viscous liquids, lubricating oils, pulp stock, solvents, and crude oil, the UF D5500 provides a reliable and cost-effective solution for difficult flow measurement applications.

Designed for full pipes and liquids containing suspended solids or gas bubbles, the UF D5500 uses advanced Doppler ultrasonic technology to measure flow externally through the pipe wall. An acoustic signal is reflected back to the sensor from particles or bubbles suspended in the liquid, allowing accurate flow measurement without any contact with the process media.

The clamp-on sensor mounts easily to the outside of metal or plastic pipes from 12.7 mm to 4500 mm in diameter, eliminating the need for pipe cutting, drilling, or process shutdowns. Because the sensor never comes into contact with the liquid, there is no fouling, scaling, pressure drop, or ongoing maintenance associated with traditional inline flow meters.

Engineered for industrial reliability, the UF D5500 features enhanced digital signal processing for improved signal stability and noise immunity, a watertight IP66/NEMA4X enclosure, large backlit display, simple 5-key calibration system, built-in 26 million point data logger, and programmable control relays.


Key Features:

  • Non-invasive clamp-on Doppler flow measurement
  • Designed for dirty, aerated, and solids-bearing liquids
  • Suitable for raw sewage, sludge, slurries, oils, solvents, and pulp stock
  • Fits pipe sizes from 12.7 mm to 4500 mm
  • No pipe cutting, drilling, or process shutdown required
  • Advanced digital signal processing for improved signal stability
  • Enhanced diagnostics and industrial noise immunity
  • Large backlit display with simple 5-key menu navigation
  • Built-in 26 million point data logger with USB download capability
  • Isolated 4-20mA output and two programmable control relays
  • Measures bidirectional flow with positive and negative indication
  • Watertight NEMA4X / IP66 enclosure
  • Compatible with most metal and plastic pipe materials

SpecificationDetails
Flow Rate Range±0.03 to 12.2 m/sec (±0.1 to 40 ft/sec) in most applications
Pipe SizeSuitable for pipe IDs from 12.7 mm to 4.5 m (½” to 180″)
Accuracy±2% of reading or 0.03 m/sec (0.1 ft/sec), whichever is greater
Measurement RequirementsRequires solids or bubbles with a minimum size of 100 microns and minimum concentration of 75 ppm
Repeatability±0.1%
Linearity±0.5%
DisplayWhite backlit matrix display showing flow rate, 16-digit totaliser, relay states, operating mode, and calibration menu
ConfigurationBuilt-in 5-key calibrator with English, French, and Spanish language selection
Power Input100–240 VAC, 50/60Hz, 10VA maximum Optional: 9–32VDC, 10 watts maximum
OutputIsolated 4–20mA (1000 ohm load max.)
Control Relays2 x programmable 5 amp 240VAC SPDT relays for flow alarms and/or proportional pulse output
Data LoggerBuilt-in 26 million point logger with USB output and Windows™ software
EnclosureWatertight and dust tight NEMA4X / IP66 polycarbonate enclosure with clear shatter-proof cover
Electronics Operating Temperature-23°C to 60°C (-10°F to 140°F)
Approximate Shipping Weight4.5 kg (10 lbs)

Sensor SpecificationDetails
Minimum Pipe Diameter12.5 mm (0.5″)
Maximum Pipe Diameter4.5 m (180″)
Sensor Operating Temperature-40°C to 150°C (-40°F to 300°F)
Operating Frequency640 KHz
Sensor Housing MaterialStainless Steel
Sensor Cable7.6 m (25 ft) shielded coaxial pair (RG174U) Optional 15 m (50 ft) or 30 m (100 ft) continuous cable available
Submersion RatingWithstands accidental submersion pressure up to 0.7 Bar (10 psi)
